Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
Johnson Controls Unitary Products 5
R / W (5) BV 39 DEMAND_VENT n/a n/a n/a
Demand Ventilation (using Inside
Sensor) Enabled
R / W (2) AV 18 DEMVENT_STPT 1000 0 5000
Demand Ventilation Setpoint
R (2) AI 67 REVISION n/a n/a xx
Device Revision
R / W (5) BV 98 DIFF_ENTH_MODE n/a n/a n/a
Differential enthalpy mode enabled
R / W (5) BV 90 DF_SW_INST n/a n/a n/a
Dirty Filter Switch Installed
R (5) BI 15 DIRT_FILT_SW n/a n/a n/a
Dirty Filter Switch Status
(0=open,1=closed / fault)
R (2) AI 35 DUCT_STATIC n/a n/a n/a
Duct Static Pressure
R / W (2) AV 58 DUCT_SP_STPT 1.5 0 5
Duct Static Pressure Setpoint
R / W (2) AV 59 DUCT_SD_STPT 4.5 0 5
Duct Static Pressure Shutdown Setpoint
R / W (2) AV 87 ECON_MIN_POS_LP 25 0 100
Econ Minimum Position For Low Speed
Fan
R (2) AI 31 ECO_DAMP_OUT n/a n/a n/a
Economizer Damper Output Status (0-
100%)
R / W (2) AV 20 ECO_1ST_STPT 55 40 65
Economizer First Stage Setpoint
R / W (5) BV 7 ECONO_INST n/a n/a n/a
Economizer Installed
R / W (5) BV 36 ECO_L_TO_SAT n/a n/a n/a
Economizer Loading to Control Supply
Air Temperature Enabled
R / W (2) AV 19 ECON_MIN_POS 20 0 100
Economizer Minimum Position
R (5) BI 31 ECONO_STATUS n/a n/a n/a
Economizer Output Status (0=not Free
Cooling, 1= Free Cooling)
R / W (2) AV 22 ECON_OAEN_SP 27 10 50
Economizer Outside Air Enthalpy
Setpoint
R / W (2) AV 23 ECON_OAT_ENA 55 40 80
Economizer Outside Air Temperature
Enable Setpoint
R / W (2) AV 84 ECON_RAEN_SP 27 10 50
Economizer Return Air Enthalpy
Setpoint
R / W (2) AV 21 ECO_2ND_STPT 50 40 65
Economizer Second Stage Setpoint
R (2) AI 41 E_C1_ACM_HRS n/a n/a n/a
Elite Compressor #1 Accumulated Run
Time (in hours)
R (5) BI 42 E_COMP1_STAT n/a n/a n/a
Elite Compressor #1 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 45 E_C1_OVRLOAD n/a n/a n/a
Elite Compressor #1 Overload Switch
Input Status (1=closed, 0=open / fault)
R (2) AI 42 E_C2_ACM_HRS n/a n/a n/a
Elite Compressor #2 Accumulated Run
Time (in hours)
R (5) BI 46 E_COMP2_STAT n/a n/a n/a
Elite Compressor #2 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 49 E_C2_OVRLOAD n/a n/a n/a
Elite Compressor #2 Overload Switch
Input Status (1=closed, 0=open / fault)
R (2) AI 43 E_C3_ACM_HRS n/a n/a n/a
Elite Compressor #3 Accumulated Run
Time (in hours)
R (5) BI 51 E_COMP3_STAT n/a n/a n/a
Elite Compressor #3 Output Status
(0=output is OFF, 1=output is ON)
TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
