Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
Johnson Controls Unitary Products 21
TROUBLESHOOTING
TABLE 4: SIMPLICITY
®
LINC GATEWAY LED TROUBLESHOOTING
Light Description
PWR This is the power light and should show steady green at all times when the Simplicity Linc is powered.
SYS ERROR
The SYS ERR LED will go on solid 15 seconds after power up. It will turn off after 5 seconds. A steady red light will
indicate there is a system error on the Simplicity Linc. If this occurs, contact UP Tech Services at 1-877-874-7378
COMM
ERROR
COMM ERR LED will go on solid 15 seconds after power up. It will turn off after 5 seconds. A steady red light will
indicate the communications problem if there is a configured node connected to the Simplicity Linc that is offline.
Config
ERROR
Config ERR LED will go on solid 15 seconds after power up. It will turn off after 5 seconds. A steady amber light will
indicate a configuration error exists in the active configuration. If this occurs, contact UP Tech Services at 1-877-
874-7378
Node Offline
Node Offline LED will go on solid 15 seconds after power up. It will turn off after 5 seconds. If the Node Offline LED
stays on solid, a node offline condition has occurred.
Unused 15 seconds after powering up the 4 unused LEDs will turn on solid for 5 seconds, then turn off.
RX On normal operation of Simplicity Linc, the RX LED will flash when a message is received on the field port.
TX On normal operation of Simplicity Linc, the TX LED will flash when a message is sent on the field port.
RUN
RUN LED will flash 20 seconds after power up, signifying normal operation. During the first 20 seconds, the LED
should be off.
General
Power Source 24 ± 15% VAC (Obtained from the Roof Top Unit)
Frequency 45 to 65 HZ
Power Consumption Nominal >2 VA
Operating Environment -40 to 160° F (-40 to 70° C) 10 to 95% non-condensing
Size (H x W x D) 5.0 x 2.4 x 1.8 in. (128 x 61 x 45.75 cm)
Weight 0.2 lb. (0.09 kg)
Processor
Type Microchip
SDRAM Memory 2048 bytes
FLASH Memory 1024 bytes w/1,000,000 write cycle capability
Interface
Port 1 Type BACnet MS/TP
Port 1 Speeds 9.6, 19.2, 38.4, 76.8 kbaud
Port 1 Connector 3-pin screw terminals
Port 2 Type Modbus RTU (RS485)
Port 2 Speeds 9.6, 19,2 kbaud
Port 2 Connector 6-pin screw terminals
LAN Cable Screened Twisted-Pair (Belden 9272 or 89272)
LEDs Controller Status; BACnet; Modbus
Switch Selections MAC Address (1-99), Baud Rate
