Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
4 Johnson Controls Unitary Products
TABLE 2: POINTS LIST IN DESCRIPTION ORDER
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
R / W (5) BV 109 COMM_IAQ n/a n/a n/a
Accept Comm Value for Indoor Quality
Sensor
R / W (5) BV 101 COMM_OAT n/a n/a n/a
Accept Comm Value for OAT
R / W (5) BV 100 COMM_OH n/a n/a n/a
Accept Comm Value for OH
R / W (5) BV 99 COMM_RH n/a n/a n/a
Accept Comm Value for RH
R / W (5) BV 108 COMM_ST n/a n/a n/a
Accept Comm Value for Space
Temperature
R / W (2) AV 14 ACC_OVER_TME n/a n/a n/a
Accumulated Unoccupied Override
Time (in hours)
R (2) AI 15 ACTIVE_ALARM n/a n/a n/a
Active Alarm
R (2) AI 86 AIR_MON_INPUT 0 0 10
Air Monitor Station Input
R (5) BI 16 AIR_PROOF_SW n/a n/a n/a
Air Proving Switch Status (1=closed,
0=open / no air flow)
R / W (2) AV 79 OAQ_STPT 1000 0 5000
Air Quality Setpoint Outside
R (5) BI 85 ALARM_1_ON n/a n/a n/a
Alarm Buffer #1 (0=Alarm has cleared,
1=Alarm is still active)
R (5) BI 86 ALARM_2_ON n/a n/a n/a
Alarm Buffer #2 (0=Alarm has cleared,
1=Alarm is still active)
R (5) BI 87 ALARM_3_ON n/a n/a n/a
Alarm Buffer #3 (0=Alarm has cleared,
1=Alarm is still active)
R (5) BI 88 ALARM_4_ON n/a n/a n/a
Alarm Buffer #4 (0=Alarm has cleared,
1=Alarm is still active)
R (5) BI 89 ALARM_5_ON n/a n/a n/a
Alarm Buffer #5 (0=Alarm has cleared,
1=Alarm is still active)
R (2) AI 33 BLDG_STATIC n/a n/a n/a
Building Static Pressure
R / W (5) BV 29 BP_SENS_INST n/a n/a n/a
Building Static Pressure Sensor
Installed
R / W (2) AV 57 BLDG_SP_STPT 0.15 -0.25 0.25
Building Static Pressure Setpoint
R / W (2) AV 25 COM_V_LOW_SP 70 60 80
Comfort Ventilation LowerSetpoint
(degrees F)
R / W (5) BV 34 CVM_COOLING n/a n/a n/a
Comfort Ventilation Mode for Cooling
Enabled
R / W (5) BV 35 CVM_HEATING n/a n/a n/a
Comfort Ventilation Mode for Heating
Enabled
R (5) BI 33 COM_VENT_STA n/a n/a n/a
Comfort Ventilation Mode Status
(1=control is in Comfort Vent mode, 0= it
is not)
R / W (2) AV 24 COM_V_HI_SP 80 65 85
Comfort Ventilation Upper Setpoint
(degrees F)
R / W (5) BV 23 COOLING_ENA n/a n/a n/a
Cooling Mode Enabled
R (2) AI 56 CV_VAV_SELEC n/a n/a n/a
CV / VAV Selected (0= Valid CV,
1=Valid VAV, 2= Invalid Value)
R / W (5) BV 21 FAN_ON_W_SEN n/a n/a n/a
CV-Indoor Fan Operates with Space
Sensor Present Option Enabled
R / W (2) AV 8 IAQ_VALUE n/a 0 5000
Demand Ventilation (IAQ) Value (PPM)
