R (5) BI 54 E_C3_OVRLOAD n/a n/a n/a
Elite Compressor #3 Overload Switch
Input Status (1=closed, 0=open / fault)
R (2) AI 44 E_C4_ACM_HRS n/a n/a n/a
Elite Compressor #4 Accumulated Run
Time (in hours)
R (5) BI 55 E_ COMP4_STAT n/a n/a n/a
Elite Compressor #4 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 58 E_C4_OVRLOAD n/a n/a n/a
Elite Compressor #4 Overload Switch
Input Status (1=closed, 0=open / fault)
R (5) BI 50 E_CFAN1_STAT n/a n/a n/a
Elite Condenser Fan #1 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 59 E_CFAN2_STAT n/a n/a n/a
Elite Condenser Fan #2 Output Status
Input Status (0=output is OFF, 1=output
is ON)
R (5) BI 41 E_FAN_ OVER n/a n/a n/a
Elite Fan Overload Switch Input Status
(1=closed, 0=open / fault)
R (5) BI 60 E_GAS_VLVE1 n/a n/a n/a
Elite Gas Valve #1 Input Status
(1=energized, 0=not energized)
R (5) BI 62 E_GAS_VLVE2 n/a n/a n/a
Elite Gas Valve #2 Input Status
(1=energized, 0=not energized)
R (5) BI 64 E_GAS_VLVE3 n/a n/a n/a
Elite Gas Valve #3 Input Status
(1=energized, 0=not energized)
R (5) BI 44 E_HPS1 n/a n/a n/a
Elite High Pressure Switch for
Compressor #1 Input Status (1=closed,
0=open / fault)
R (5) BI 48 E_HPS2 n/a n/a n/a
Elite High Pressure Switch for
Compressor #2 Input Status (1=closed,
0=open / fault)
R (5) BI 53 E_HPS3 n/a n/a n/a
Elite High Pressure Switch for
Compressor #3 Input Status (1=closed,
0=open / fault)
R (5) BI 57 E_HPS4 n/a n/a n/a
Elite High Pressure Switch for
Compressor #4 Input Status (1=closed,
0=open / fault)
R (5) BI 40 E_IFAN_STAT n/a n/a n/a
Elite Indoor Fan Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 61 E_LIMIT_ 1 n/a n/a n/a
Elite Limit Switch #1 Input Status
(1=closed, 0=open / fault)
R (5) BI 63 E_LIMIT_ 2 n/a n/a n/a
Elite Limit Switch #2 Input Status
(1=closed, 0=open / fault)
R (5) BI 65 E_LIMIT_ 3 n/a n/a n/a
Elite Limit Switch #3 Input Status
(1=closed, 0=open / fault)
R (5) BI 43 E_LPS1 n/a n/a n/a
Elite Low Pressure Switch for
Compressor #1 Input Status (1=closed,
0=open / fault)
TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
