Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
Johnson Controls Unitary Products 7
R (5) BI 47 E_LPS2 n/a n/a n/a
Elite Low Pressure Switch for
Compressor #2 Input Status (1=closed,
0=open / fault)
R (5) BI 52 E_LPS3 n/a n/a n/a
Elite Low Pressure Switch for
Compressor #3 Input Status (1=closed,
0=open / fault)
R (5) BI 56 E_LPS4 n/a n/a n/a
Elite Low Pressure Switch for
Compressor #4 Input Status (1=closed,
0=open / fault)
R (2) AI 32 EXH_DAMP_OUT n/a n/a n/a
Exhaust Damper Output Status (0-
100%)
R (5) BI 30 EX_FAN_STAT n/a n/a n/a
Exhaust Fan Output Status (0=output is
OFF, 1=output is ON)
R / W (5) BV 10 EX_VFD_INST n/a n/a n/a
Exhaust VFD Installed
R / W (2) AV 91 FAN_SPD_1ST_COOL 70 0 100
Fan Speed: 1st Stage Cooling
R / W (2) AV 92 FAN_SPD_1ST_HEAT 100 0 100
Fan Speed: 1st Stage Heating
R / W (2) AV 93 FAN_SPD_ALL_COOL 100 0 100
Fan Speed: All Stages Cooling
R / W (2) AV 94 FAN_SPD_ALL_HEAT 100 0 100
Fan Speed: All Stages Heating
R / W (2) AV 90 FAN_SPD_NO_HEAT_COOL 50 0 100
Fan Speed: No Heating No Cooling
R (5) BI 102 4_STG_EXP_PRES n/a n/a n/a
Four Stage Expansion board Present
R (5) BI 32 FRECOOL_STAT n/a n/a n/a
Free Cooling Mode Status (0=comps
not overridden by Econo, 1=comps
overridden)
R (5) BI 104 FREEZE_STAT_1 n/a n/a n/a
Freeze Stat # 1
R (5) BI 105 FREEZE_STAT_2 n/a n/a n/a
Freeze Stat # 2
R (5) BI 106 FREEZE_STAT_3 n/a n/a n/a
Freeze Stat # 3
R (5) BI 107 FREEZE_STAT_4 n/a n/a n/a
Freeze Stat # 4
R (5) BI 68 HEAT_1_STAT n/a n/a n/a
H1 Heating Output #1 Status (0=output
is OFF, 1=output is ON)
R (5) BI 69 HEAT_2_STAT n/a n/a n/a
H2 Heating Output #2 Status (0=output
is OFF, 1=output is ON)
R (5) BI 70 HEAT_3_STAT n/a n/a n/a
H3 Heating Output #3 Status (0=output
is OFF, 1=output is ON)
R (2) AI 76 H1_ACCUM_HRS n/a n/a n/a
Heating #1 Accumulated Run Time (in
hours)
R (2) AI 77 H2_ACCUM_HRS n/a n/a n/a
Heating #2 Accumulated Run Time (in
hours)
R (2) AI 78 H3_ACCUM_HRS n/a n/a n/a
Heating #3 Accumulated Run Time (in
hours)
R / W (5) BV 25 HEATING_ENA n/a n/a n/a
Heating Mode Enabled
R / W (2) AV 27 HGR_HUM_STPT 50 0 100
Hot Gas Reheat Humidity Setpoint
(percent Humidity)
R (5) BI 18 HGR_STAT n/a n/a n/a
Hot Gas Reheat Output Status
(0=output is OFF, 1=output is ON)
TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
