1031990-UAD-A-0313
8 Johnson Controls Unitary Products
R (2) AI 47 HGR_VLV_OUT n/a n/a n/a
Hot Gas Reheat Valve Output Status (0-
100%)
R (5) BI 66 E_FREEZE_ST n/a n/a n/a
Hot H2O Freeze Thermostat Switch
Input Status (1=closed, 0=open / fault)
R (2) AI 55 HW_VLV_OUT n/a n/a n/a
Hot Water Valve Output Status (0-
100%)
R / W (5) BV 2 HYDRONC_HEAT n/a n/a n/a
Hydronic Heat Enabled
R / W (5) BV 3 HH_REVER_VLV n/a n/a n/a
Hydronic Heat Reverse Actuated Valve
Installed
R / W (2) AV 62 HYD_S1_SA_SP 120 80 180
Hydronic Heating Stage #1 Supply Air
Setpoint (degrees F)
R / W (2) AV 63 HYD_S2_SA_SP 150 81 180
Hydronic Heating Stage #2 Supply Air
Setpoint (degrees F)
R / W (2) AV 80 IO_DVNT_STPT 700 0 2000
Indoor / Outdoor Demand Ventilation
Setpoint
R (2) AI 45 I_C1_ACM_HRS n/a n/a n/a
Intelli-Comfort Compressor #1
Accumulated Run Time (in hours)
R (5) BI 73 I_COMP1_STAT n/a n/a n/a
Intelli-Comfort Compressor #1 Input
Status (0=output is OFF, 1=output is
ON)
R (2) AI 46 I_C2_ACM_HRS n/a n/a n/a
Intelli-Comfort Compressor #2
Accumulated Run Time (in hours)
R (5) BI 76 I_COMP2_STAT n/a n/a n/a
Intelli-Comfort Compressor #2 Input
Status (0=output is OFF, 1=output is
ON)
R (5) BI 79 I_CFAN_STAT n/a n/a n/a
Intelli-Comfort Condenser Fan #1 Input
Status (0=output is OFF, 1=output is
ON)
R (5) BI 72 I_FAN_OVER n/a n/a n/a
Intelli-Comfort Fan Overload Switch
Input Status (0=open,1=closed)
R (5) BI 82 I_FREEZE_1 n/a n/a n/a
Intelli-Comfort Freeze Thermostat
Switch #1 Input Status
(0=open,1=closed)
R (5) BI 83 I_FREEZE_2 n/a n/a n/a
Intelli-Comfort Freeze Thermostat
Switch #2 Input Status
(0=open,1=closed)
R (5) BI 80 I_GAS_VLVE1 n/a n/a n/a
Intelli-Comfort Gas Valve #1 Input
Status
R (5) BI 75 I_HPS1 n/a n/a n/a
Intelli-Comfort High Pressure Switch for
Compressor #1 Input Status (1=closed,
0=open / fault)
R (5) BI 78 I_HPS2 n/a n/a n/a
Intelli-Comfort High Pressure Switch for
Compressor #2 Input Status (1=closed,
0=open / fault)
R (5) BI 71 I_IFAN_STAT n/a n/a n/a
Intelli-Comfort Indoor Fan Output Status
(0=output is OFF, 1=output is ON)
TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
