Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
Johnson Controls Unitary Products 9
R (5) BI 81 I_LIMIT_1 n/a n/a n/a
Intelli-Comfort Limit Switch #1 Input
Status
R (5) BI 74 I_LPS1 n/a n/a n/a
Intelli-Comfort Low Pressure Switch for
Compressor #1 Input Status (1=closed,
0=open / fault)
R (5) BI 77 I_LPS2 n/a n/a n/a
Intelli-Comfort Low Pressure Switch for
Compressor #2 Input Status (1=closed,
0=open / fault)
R / W (5) BV 28 INTELLI-STRT n/a n/a n/a
Intelli-Start Enabled
R / W (5) BV 13 LOADSHED n/a n/a n/a
Loadshed (0=clear loadshed, 1=set
loadshed operation)
R / W (2) AV 89 LOW_AMB_ECON_MIN 0 0 99
Low Ambient Economizer Minimum
Position (Percent) (0 disables)
R / W (2) AV 88 LOW_AMB_ECON_STPT 0 0 60
Low Ambient Economizer Temperature
Setpoint (0 disables)
R / W (5) BV 19 LOW_AMB_OVRD n/a n/a n/a
Low Ambient Temperature (0=comps
not overridden by LAT, 1=comps
overridden)
R (5) BI 14 LOW_SUP_VOLT n/a n/a n/a
Low Supply Voltage (0=comps not
overridden by LSV, 1=comps
overridden)
R / W (2) AV 28 MAX_TH_OFSET 3 0 5
Max Temperature / Humidity Setpoint
Offset
R / W (2) AV 30 MAX_DMV_ECON 50 0 100
Maximum Demand Ventillation
Economizer Position
R / W (5) BV 110 MIN_AMB_SEN n/a n/a n/a
Minimum Outdoor Air Sensor Enabled
R / W (2) AV 85 MIN_AMB_TEMP_SP 0 0 100%
Minimum Outdoor Air Temperature
Setpoint (0-100%)
R (5) BI 11 MODBUS_ALARM n/a n/a n/a
Modbus Communication Alarm
R / W (5) BV 9 MOD_EX_INST n/a n/a n/a
Modulating Exhaust Installed
R / W (2) AV 61 MWU_RAT_STPT 70 50 85
Morning Warm-Up and VAV Heating:
Return Air Temperature Setpoint
(degrees F)
R / W (5) BV 6 MORN_WARM-UP n/a n/a n/a
Morning Warm-Up Enabled
R (2) AI 16 NUMBER_COMPS 2 4
Number of Compressors Available
R (2) AI 48 NUMBER_HEAT n/a n/a n/a
Number of Heat Stages Available (0,0, 0
stage, 0,1= 1 stage, 1,0= 2 stage, 1,1= 3
stage)
R / W (2) AV 1 OCC_COOL_SP 72 46 99
Occupied Cooling Setpoint
R / W (2) AV 50 OCC_HEAT_SP 68 45 98
Occupied Heating Setpoint
R / W (5) BV 1 OCCUPIED_ENA n/a n/a n/a
Occupied Input Enabled
R / W (5) BV 93 OCC_COMS_ENA n/a n/a n/a
Occupied Thermostat or
Communication Input Enabled
R (2) AI 17 OP_COOL_STPT n/a n/a n/a
Operating Cooling Setpoint
R (2) AI 49 OP_HEAT_STPT 68 45 99
Operating Heating Setpoint
TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
