Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
10 Johnson Controls Unitary Products
R / W (2) AV 69 OP_STPT_DIF 1 1 5
Operating Setpoint Differential
R / W (2) AV 74 OAT_COOL_L_O 45 0 100
Outdoor Air Temperature Cooling
Lockout Temperature
R / W (2) AV 54 OAT_HEAT_L_O 75 0 100
Outdoor Air Temperature
HeatingLockout Temperature
R (2) AI 11 AMB_AIR_ENTH n/a n/a n/a
Outside Air Enthalpy
R / W (2) AV 10 AMB_AIR_HUM n/a n/a n/a
Outside Air Humidity
R / W (5) BV 37 OAH_SENSOR n/a n/a n/a
Outside Air Humidity Sensor Enabled
R / W (2) AV 7 AMB_TEMP n/a n/a n/a
Outside Air Temperature
R (2) AI 9 OAQ_VALUE n/a 0 5000
Outside Demand Ventilation (OAQ)
Value (PPM)
R / W (5) BV 8 PWR_EX_INST n/a n/a n/a
Power Exhaust Installed
R / W (5) BV 20 POP_ENABLED n/a n/a n/a
Pre-Occupancy Purge Enabled
R / W (2) AV 81 POP_HOURS 4 0 23
Pre-Occupancy Purge Time (hours)
R / W (2) AV 82 POP_MINUTES 0 0 59
Pre-Occupancy Purge Time (minutes)
R (5) BI 17 PURGE_SWITCH n/a n/a n/a
Purge Switch Status (0=open,1=closed)
R / W (5) BV 12 REDLINE n/a n/a n/a
Redline (0=clear redline, 1=set redline
operation)
R (5) BI 4 REM_CONT_ENA n/a n/a n/a
Remote Control Enabled
R / W (5) BV 111 REM_CONT_BAS_ECON n/a n/a n/a
Remote Control Third Party BAS
Economizer Enable
R (2) AI 13 RET_AIR_ENTH n/a n/a n/a
Return Air Enthalpy
R / W (2) AV 12 RET_AIR_HUM n/a n/a n/a
Return Air Humidity
R (2) AI 5 RET_AIR_TEMP n/a n/a n/a
Return Air Temperature
R / W (5) BV 38 RAH_SENSOR n/a n/a n/a
Return/Inside Air Humidity Sensor
Enabled
R / W (2) AV 6 SPACE_TEMP n/a n/a n/a
Space (Indoor) Air Temperature
R / W (2) AV 71 SPCE_ALM_TMP 0 0 25
Space Sensor Alarm Temperature
(degrees F, 0 = disabled)
R / W (2) AV 72 SPCE_ALM_TIM 0 0 120
Space Sensor Alarm Time (minutes F, 0
= disabled)
R / W (5) BV 26 SEN_FAULT_EN n/a n/a n/a
Space Sensor Fault Override
(Construction Mode) Enabled
R / W (2) AV 73 SP_OFF_RANGE 3 0 5
Space Temprature Sensor Offset Range
(0-5 degrees)
R (2) AI 4 SUP_AIR_TEMP n/a n/a n/a
Supply Air Temperature
R / W (2) AV 70 SAT_ALM_COOL 0 0 80
Supply Air Temperature Alarm Setpoint
for Cooling
R / W (2) AV 53 SAT_ALM_HEAT 0 0 120
Supply Air Temperature Alarm Setpoint
for Heating
R / W (5) BV 22 SAT_COOLING n/a n/a n/a
Supply Air Temperature Limit for
Cooling Enabled
R / W (2) AV 3 SAT_COOL_SP 50 40 65
Supply Air Temperature Limit for
Cooling Setpoint (degrees F)
TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
