1031990-UAD-A-0313
Johnson Controls Unitary Products 11
R / W (5) BV 24 SAT_HEATING n/a n/a n/a
Supply Air Temperature Limit for
Heating Enabled
R / W (2) AV 52 SAT_HEAT_SP 135 100 180
Supply Air Temperature Limit for
Heating Setpoint (degrees F)
R (2) AI 34 SFAN_VFD_OUT n/a n/a n/a
Supply Fan VFD Output Status (0-
100%)
R (2) AI 36 ALARM_1 n/a n/a n/a
System Alarm #1
R (2) AI 37 ALARM_2 n/a n/a n/a
System Alarm #2
R (2) AI 38 ALARM_3 n/a n/a n/a
System Alarm #3
R (2) AI 39 ALARM_4 n/a n/a n/a
System Alarm #4
R (2) AI 40 ALARM_5 n/a n/a n/a
System Alarm #5
R / W (2) AV 29 TH_OFFSET 5 1 10
Temperature / Humidity % Humidity that
= 1°F of Offset
R / W (2) AV 26 TEM_HUM_STPT 50 20 80
Temperature / Humidity Setpoint
(percent Humidity)
R / W (5) BV 97 THERMO_CONTROL n/a n/a n/a
Thermostat Only Control Enable
R / W (5) BV 67 FAN_HEAT n/a n/a n/a
Turn OFF Continuous Fan when
Starting Heat Enabled (0=Continuous
Fan ON)
R / W (2) AV 2 UNOC_COOL_SP 85 46 99
Un-Occupied Cooling Setpoint
R / W (2) AV 51 UNOC_HEAT_SP 60 45 98
Un-Occupied Heating Setpoint
R / W (2) AV 75 UNOC_OVR_TP 60 0 240
Unoccupied Override Time Period
R (5) BI 103 VAV_INTELLI_2_PRES n/a n/a n/a
VAV / Intelli-Comfort 2 Expansion Board
Present
R / W (2) AV 65 VAV_CL_LO_SP 55 40 69
VAV Cooling Supply Air Temperature:
Lower Setpoint (degrees F)
R / W (2) AV 66 VAV_SAT_RSET 72 40 85
VAV Cooling Supply Air Temperature:
Reset Setpoint (Space
Temperature)(degrees F)
R / W (2) AV 64 VAV_CL_HI_SP 60 41 70
VAV Cooling Supply Air Temperature:
Upper Setpoint (degrees F)
R / W (5) BV 5 VAV_OCC_HEAT n/a n/a n/a
VAV Occupied Heating Enabled
R / W (2) AV 60 VAV_OHEAT_SP 68 40 85
VAV Occupied Heating Setpoint
(degrees F)
R / W (5) BV 96 VAV_UNOCC_HEAT n/a n/a n/a
VAV Unoccupied Heating Enabled
TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
