Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
12 Johnson Controls Unitary Products
TABLE 3: POINTS LIST IN OBJECT ORDER
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
R / W (2) AV 1 OCC_COOL_SP 72 46 99
Occupied Cooling Setpoint
R / W (2) AV 2 UNOC_COOL_SP 85 46 99
Un-Occupied Cooling Setpoint
R / W (2) AV 3 SAT_COOL_SP 50 40 65
Supply Air Temperature Limit for
Cooling Setpoint (degrees F)
R (2) AI 4 SUP_AIR_TEMP n/a n/a n/a
Supply Air Temperature
R (2) AI 5 RET_AIR_TEMP n/a n/a n/a
Return Air Temperature
R / W (2) AV 6 SPACE_TEMP n/a n/a n/a
Space (Indoor) Air Temperature
R / W (2) AV 7 AMB_TEMP n/a n/a n/a
Outside Air Temperature
R / W (2) AV 8 IAQ_VALUE n/a 0 5000
Demand Ventilation (IAQ) Value (PPM)
R (2) AI 9 OAQ_VALUE n/a 0 5000
Outside Demand Ventilation (OAQ)
Value (PPM)
R / W (2) AV 10 AMB_AIR_HUM n/a n/a n/a
Outside Air Humidity
R (2) AI 11 AMB_AIR_ENTH n/a n/a n/a
Outside Air Enthalpy
R / W (2) AV 12 RET_AIR_HUM n/a n/a n/a
Return Air Humidity
R (2) AI 13 RET_AIR_ENTH n/a n/a n/a
Return Air Enthalpy
R / W (2) AV 14 ACC_OVER_TME n/a n/a n/a
Accumulated Unoccupied Override
Time (in hours)
R (2) AI 15 ACTIVE_ALARM n/a n/a n/a
Active Alarm
R (2) AI 16 NUMBER_COMPS 2 4
Number of Compressors Available
R (2) AI 17 OP_COOL_STPT n/a n/a n/a
Operating Cooling Setpoint
R / W (2) AV 18 DEMVENT_STPT 1000 0 5000
Demand Ventilation Setpoint
R / W (2) AV 19 ECON_MIN_POS 20 0 100
Economizer Minimum Position
R / W (2) AV 20 ECO_1ST_STPT 55 40 65
Economizer First Stage Setpoint
R / W (2) AV 21 ECO_2ND_STPT 50 40 65
Economizer Second Stage Setpoint
R / W (2) AV 22 ECON_OAEN_SP 27 10 50
Economizer Outside Air Enthalpy
Setpoint
R / W (2) AV 23 ECON_OAT_ENA 55 40 80
Economizer Outside Air Temperature
Enable Setpoint
R / W (2) AV 24 COM_V_HI_SP 80 65 85
Comfort Ventilation Upper Setpoint
(degrees F)
R / W (2) AV 25 COM_V_LOW_SP 70 60 80
Comfort Ventilation LowerSetpoint
(degrees F)
R / W (2) AV 26 TEM_HUM_STPT 50 20 80
Temperature / Humidity Setpoint
(percent Humidity)
R / W (2) AV 27 HGR_HUM_STPT 50 0 100
Hot Gas Reheat Humidity Setpoint
(percent Humidity)
R / W (2) AV 28 MAX_TH_OFSET 3 0 5
Max Temperature / Humidity Setpoint
Offset
