Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
Johnson Controls Unitary Products 13
R / W (2) AV 29 TH_OFFSET 5 1 10
Temperature / Humidity % Humidity
that = 1°F of Offset
R / W (2) AV 30 MAX_DMV_ECON 50 0 100
Maximum Demand Ventillation
Economizer Position
R (2) AI 31 ECO_DAMP_OUT n/a n/a n/a
Economizer Damper Output Status (0-
100%)
R (2) AI 32 EXH_DAMP_OUT n/a n/a n/a
Exhaust Damper Output Status (0-
100%)
R (2) AI 33 BLDG_STATIC n/a n/a n/a
Building Static Pressure
R (2) AI 34 SFAN_VFD_OUT n/a n/a n/a
Supply Fan VFD Output Status (0-
100%)
R (2) AI 35 DUCT_STATIC n/a n/a n/a
Duct Static Pressure
R (2) AI 36 ALARM_1 n/a n/a n/a
System Alarm #1
R (2) AI 37 ALARM_2 n/a n/a n/a
System Alarm #2
R (2) AI 38 ALARM_3 n/a n/a n/a
System Alarm #3
R (2) AI 39 ALARM_4 n/a n/a n/a
System Alarm #4
R (2) AI 40 ALARM_5 n/a n/a n/a
System Alarm #5
R (2) AI 41 E_C1_ACM_HRS n/a n/a n/a
Elite Compressor #1 Accumulated Run
Time (in hours)
R (2) AI 42 E_C2_ACM_HRS n/a n/a n/a
Elite Compressor #2 Accumulated Run
Time (in hours)
R (2) AI 43 E_C3_ACM_HRS n/a n/a n/a
Elite Compressor #3 Accumulated Run
Time (in hours)
R (2) AI 44 E_C4_ACM_HRS n/a n/a n/a
Elite Compressor #4 Accumulated Run
Time (in hours)
R (2) AI 45 I_C1_ACM_HRS n/a n/a n/a
Intelli-Comfort Compressor #1
Accumulated Run Time (in hours)
R (2) AI 46 I_C2_ACM_HRS n/a n/a n/a
Intelli-Comfort Compressor #2
Accumulated Run Time (in hours)
R (2) AI 47 HGR_VLV_OUT n/a n/a n/a
Hot Gas Reheat Valve Output Status
(0-100%)
R (2) AI 48 NUMBER_HEAT n/a n/a n/a
Number of Heat Stages Available (0,0,
0 stage, 0,1= 1 stage, 1,0= 2 stage,
1,1= 3 stage)
R (2) AI 49 OP_HEAT_STPT 68 45 99
Operating Heating Setpoint
R / W
(2) AV
50 OCC_HEAT_SP 68 45 98 Occupied Heating Setpoint
R / W
(2) AV
51 UNOC_HEAT_SP 60 45 98 Un-Occupied Heating Setpoint
R / W
(2) AV
52 SAT_HEAT_SP 135 100 180 Supply Air Temperature Limit for
Heating Setpoint (degrees F)
R / W
(2) AV
53 SAT_ALM_HEAT 0 0 120 Supply Air Temperature Alarm
Setpoint for Heating
TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
