(2) AV
54 OAT_HEAT_L_O 75 0 100 Outdoor Air Temperature
HeatingLockout Temperature
R
(2) AI
55 HW_VLV_OUT n/a n/a n/a Hot Water Valve Output Status (0-
100%)
R
(2) AI
56 CV_VAV_SELEC n/a n/a n/a CV / VAV Selected (0= Valid CV,
1=Valid VAV, 2= Invalid Value)
R / W
(2) AV
57 BLDG_SP_STPT 0.15 -0.25 0.25 Building Static Pressure Setpoint
R / W
(2) AV
58 DUCT_SP_STPT 1.5 0 5 Duct Static Pressure Setpoint
R / W
(2) AV
59 DUCT_SD_STPT 4.5 0 5 Duct Static Pressure Shutdown
Setpoint
R / W
(2) AV
60 VAV_OHEAT_SP 68 40 85 VAV Occupied Heating Setpoint
(degrees F)
R / W
(2) AV
61 MWU_RAT_STPT 70 50 85 Morning Warm-Up and VAV Heating:
Return Air Temperature Setpoint
(degrees F)
R / W
(2) AV
62 HYD_S1_SA_SP 120 80 180 Hydronic Heating Stage #1 Supply Air
Setpoint (degrees F)
R / W
(2) AV
63 HYD_S2_SA_SP 150 81 180 Hydronic Heating Stage #2 Supply Air
Setpoint (degrees F)
R / W
(2) AV
64 VAV_CL_HI_SP 60 41 70 VAV Cooling Supply Air Temperature:
Upper Setpoint (degrees F)
R / W
(2) AV
65 VAV_CL_LO_SP 55 40 69 VAV Cooling Supply Air Temperature:
Lower Setpoint (degrees F)
R / W
(2) AV
66 VAV_SAT_RSET 72 40 85 VAV Cooling Supply Air Temperature:
Reset Setpoint (Space
Temperature)(degrees F)
R
(2) AI
67 REVISION n/a n/a xx Device Revision
R / W
(2) AV
69 OP_STPT_DIF 1 1 5 Operating Setpoint Differential
R / W
(2) AV
70 SAT_ALM_COOL 0 0 80 Supply Air Temperature Alarm
Setpoint for Cooling
R / W
(2) AV
71 SPCE_ALM_TMP 0 0 25 Space Sensor Alarm Temperature
(degrees F, 0 = disabled)
R / W
(2) AV
72 SPCE_ALM_TIM 0 0 120 Space Sensor Alarm Time (minutes F,
0 = disabled)
R / W
(2) AV
73 SP_OFF_RANGE 3 0 5 Space Temprature Sensor Offset
Range (0-5 degrees)
R / W
(2) AV
74 OAT_COOL_L_O 45 0 100 Outdoor Air Temperature Cooling
Lockout Temperature
R / W
(2) AV
75 UNOC_OVR_TP 60 0 240 Unoccupied Override Time Period
R
(2) AI
76 H1_ACCUM_HRS n/a n/a n/a Heating #1 Accumulated Run Time (in
hours)
TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
