Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
Johnson Controls Unitary Products 15
R
(2) AI
77 H2_ACCUM_HRS n/a n/a n/a Heating #2 Accumulated Run Time (in
hours)
R
(2) AI
78 H3_ACCUM_HRS n/a n/a n/a Heating #3 Accumulated Run Time (in
hours)
R / W
(2) AV
79 OAQ_STPT 1000 0 5000 Air Quality Setpoint Outside
R / W
(2) AV
80 IO_DVNT_STPT 700 0 2000 Indoor / Outdoor Demand Ventilation
Setpoint
R / W
(2) AV
81 POP_HOURS 4 0 23 Pre-Occupancy Purge Time (hours)
R / W
(2) AV
82 POP_MINUTES 0 0 59 Pre-Occupancy Purge Time (minutes)
R / W
(2) AV
84 ECON_RAEN_SP 27 10 50 Economizer Return Air Enthalpy
Setpoint
R / W
(2) AV
85 MIN_AMB_TEMP_SP 0 0 100% Minimum Outdoor Air Temperature
Setpoint (0-100%)
R
(2) AI
86 AIR_MON_INPUT 0 0 10 Air Monitor Station Input
R / W
(2) AV
87 ECON_MIN_POS_LP 25 0 100 Econ Minimum Position For Low
Speed Fan
R / W
(2) AV
88 LOW_AMB_ECON_STP
T
0 0 60 Low Ambient Economizer Temperature
Setpoint (0 disables)
R / W
(2) AV
89 LOW_AMB_ECON_MIN 0 0 99 Low Ambient Economizer Minimum
Position (Percent) (0 disables)
R / W
(2) AV
90 FAN_SPD_NO_HEAT_C
OOL
50 0 100 Fan Speed: No Heating No Cooling
R / W
(2) AV
91 FAN_SPD_1ST_COOL 70 0 100 Fan Speed: 1st Stage Cooling
R / W
(2) AV
92 FAN_SPD_1ST_HEAT 100 0 100 Fan Speed: 1st Stage Heating
R / W
(2) AV
93 FAN_SPD_ALL_COOL 100 0 100 Fan Speed: All Stages Cooling
R / W
(2) AV
94 FAN_SPD_ALL_HEAT 100 0 100 Fan Speed: All Stages Heating
R / W (5) BV 1 OCCUPIED_ENA n/a n/a n/a Occupied Input Enabled
R / W (5) BV 2 HYDRONC_HEAT n/a n/a n/a Hydronic Heat Enabled
R / W (5) BV 3 HH_REVER_VLV n/a n/a n/a Hydronic Heat Reverse Actuated Valve
Installed
R (5) BI 4 REM_CONT_ENA n/a n/a n/a Remote Control Enabled
R / W (5) BV 5 VAV_OCC_HEAT n/a n/a n/a VAV Occupied Heating Enabled
R / W (5) BV 6 MORN_WARM-UP n/a n/a n/a Morning Warm-Up Enabled
R / W (5) BV 7 ECONO_INST n/a n/a n/a Economizer Installed
R / W (5) BV 8 PWR_EX_INST n/a n/a n/a Power Exhaust Installed
R / W (5) BV 9 MOD_EX_INST n/a n/a n/a Modulating Exhaust Installed
R / W (5) BV 10 EX_VFD_INST n/a n/a n/a Exhaust VFD Installed
R (5) BI 11 MODBUS_ALARM n/a n/a n/a Modbus Communication Alarm
TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
