Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
16 Johnson Controls Unitary Products
R / W (5) BV 12 REDLINE n/a n/a n/a Redline (0=clear redline, 1=set redline
operation)
R / W (5) BV 13 LOADSHED n/a n/a n/a Loadshed (0=clear loadshed, 1=set
loadshed operation)
R (5) BI 14 LOW_SUP_VOLT n/a n/a n/a Low Supply Voltage (0=comps not
overridden by LSV, 1=comps
overridden)
R (5) BI 15 DIRT_FILT_SW n/a n/a n/a Dirty Filter Switch Status
(0=open,1=closed / fault)
R (5) BI 16 AIR_PROOF_SW n/a n/a n/a Air Proving Switch Status (1=closed,
0=open / no air flow)
R (5) BI 17 PURGE_SWITCH n/a n/a n/a Purge Switch Status
(0=open,1=closed)
R (5) BI 18 HGR_STAT n/a n/a n/a Hot Gas Reheat Output Status
(0=output is OFF, 1=output is ON)
R / W (5) BV 19 LOW_AMB_OVRD n/a n/a n/a Low Ambient Temperature (0=comps
not overridden by LAT, 1=comps
overridden)
R / W (5) BV 20 POP_ENABLED n/a n/a n/a Pre-Occupancy Purge Enabled
R / W (5) BV 21 FAN_ON_W_SEN n/a n/a n/a CV-Indoor Fan Operates with Space
Sensor Present Option Enabled
R / W (5) BV 22 SAT_COOLING n/a n/a n/a Supply Air Temperature Limit for
Cooling Enabled
R / W (5) BV 23 COOLING_ENA n/a n/a n/a Cooling Mode Enabled
R / W (5) BV 24 SAT_HEATING n/a n/a n/a Supply Air Temperature Limit for
Heating Enabled
R / W (5) BV 25 HEATING_ENA n/a n/a n/a Heating Mode Enabled
R / W (5) BV 26 SEN_FAULT_EN n/a n/a n/a Space Sensor Fault Override
(Construction Mode) Enabled
R / W (5) BV 28 INTELLI-STRT n/a n/a n/a Intelli-Start Enabled
R / W (5) BV 29 BP_SENS_INST n/a n/a n/a Building Static Pressure Sensor
Installed
R (5) BI 30 EX_FAN_STAT n/a n/a n/a Exhaust Fan Output Status (0=output
is OFF, 1=output is ON)
R (5) BI 31 ECONO_STATUS n/a n/a n/a Economizer Output Status (0=not Free
Cooling, 1= Free Cooling)
R (5) BI 32 FRECOOL_STAT n/a n/a n/a Free Cooling Mode Status (0=comps
not overridden by Econo, 1=comps
overridden)
R (5) BI 33 COM_VENT_STA n/a n/a n/a Comfort Ventilation Mode Status
(1=control is in Comfort Vent mode, 0=
it is not)
TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
