R / W (5) BV 34 CVM_COOLING n/a n/a n/a Comfort Ventilation Mode for Cooling
Enabled
R / W (5) BV 35 CVM_HEATING n/a n/a n/a Comfort Ventilation Mode for Heating
Enabled
R / W (5) BV 36 ECO_L_TO_SAT n/a n/a n/a Economizer Loading to Control Supply
Air Temperature Enabled
R / W (5) BV 37 OAH_SENSOR n/a n/a n/a Outside Air Humidity Sensor Enabled
R / W (5) BV 38 RAH_SENSOR n/a n/a n/a Return/Inside Air Humidity Sensor
Enabled
R / W (5) BV 39 DEMAND_VENT n/a n/a n/a Demand Ventilation (using Inside
Sensor) Enabled
R (5) BI 40 E_IFAN_STAT n/a n/a n/a Elite Indoor Fan Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 41 E_FAN_ OVER n/a n/a n/a Elite Fan Overload Switch Input Status
(1=closed, 0=open / fault)
R (5) BI 42 E_COMP1_STAT n/a n/a n/a Elite Compressor #1 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 43 E_LPS1 n/a n/a n/a Elite Low Pressure Switch for
Compressor #1 Input Status (1=closed,
0=open / fault)
R (5) BI 44 E_HPS1 n/a n/a n/a Elite High Pressure Switch for
Compressor #1 Input Status (1=closed,
0=open / fault)
R (5) BI 45 E_C1_OVRLOAD n/a n/a n/a Elite Compressor #1 Overload Switch
Input Status (1=closed, 0=open / fault)
R (5) BI 46 E_COMP2_STAT n/a n/a n/a Elite Compressor #2 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 47 E_LPS2 n/a n/a n/a Elite Low Pressure Switch for
Compressor #2 Input Status (1=closed,
0=open / fault)
R (5) BI 48 E_HPS2 n/a n/a n/a Elite High Pressure Switch for
Compressor #2 Input Status (1=closed,
0=open / fault)
R (5) BI 49 E_C2_OVRLOAD n/a n/a n/a Elite Compressor #2 Overload Switch
Input Status (1=closed, 0=open / fault)
R (5) BI 50 E_CFAN1_STAT n/a n/a n/a Elite Condenser Fan #1 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 51 E_COMP3_STAT n/a n/a n/a Elite Compressor #3 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 52 E_LPS3 n/a n/a n/a Elite Low Pressure Switch for
Compressor #3 Input Status (1=closed,
0=open / fault)
TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
