Johnson Controls Simplicity LINC User Manual

1031990-UAD-A-0313
18 Johnson Controls Unitary Products
R (5) BI 53 E_HPS3 n/a n/a n/a Elite High Pressure Switch for
Compressor #3 Input Status (1=closed,
0=open / fault)
R (5) BI 54 E_C3_OVRLOAD n/a n/a n/a Elite Compressor #3 Overload Switch
Input Status (1=closed, 0=open / fault)
R (5) BI 55 E_ COMP4_STAT n/a n/a n/a Elite Compressor #4 Output Status
(0=output is OFF, 1=output is ON)
R (5) BI 56 E_LPS4 n/a n/a n/a Elite Low Pressure Switch for
Compressor #4 Input Status (1=closed,
0=open / fault)
R (5) BI 57 E_HPS4 n/a n/a n/a Elite High Pressure Switch for
Compressor #4 Input Status (1=closed,
0=open / fault)
R (5) BI 58 E_C4_OVRLOAD n/a n/a n/a Elite Compressor #4 Overload Switch
Input Status (1=closed, 0=open / fault)
R (5) BI 59 E_CFAN2_STAT n/a n/a n/a Elite Condenser Fan #2 Output Status
Input Status (0=output is OFF,
1=output is ON)
R (5) BI 60 E_GAS_VLVE1 n/a n/a n/a Elite Gas Valve #1 Input Status
(1=energized, 0=not energized)
R (5) BI 61 E_LIMIT_ 1 n/a n/a n/a Elite Limit Switch #1 Input Status
(1=closed, 0=open / fault)
R (5) BI 62 E_GAS_VLVE2 n/a n/a n/a Elite Gas Valve #2 Input Status
(1=energized, 0=not energized)
R (5) BI 63 E_LIMIT_ 2 n/a n/a n/a Elite Limit Switch #2 Input Status
(1=closed, 0=open / fault)
R (5) BI 64 E_GAS_VLVE3 n/a n/a n/a Elite Gas Valve #3 Input Status
(1=energized, 0=not energized)
R (5) BI 65 E_LIMIT_ 3 n/a n/a n/a Elite Limit Switch #3 Input Status
(1=closed, 0=open / fault)
R (5) BI 66 E_FREEZE_ST n/a n/a n/a Hot H2O Freeze Thermostat Switch
Input Status (1=closed, 0=open / fault)
R / W (5) BV 67 FAN_HEAT n/a n/a n/a Turn OFF Continuous Fan when
Starting Heat Enabled (0=Continuous
Fan ON)
R (5) BI 68 HEAT_1_STAT n/a n/a n/a H1 Heating Output #1 Status (0=output
is OFF, 1=output is ON)
R (5) BI 69 HEAT_2_STAT n/a n/a n/a H2 Heating Output #2 Status (0=output
is OFF, 1=output is ON)
R (5) BI 70 HEAT_3_STAT n/a n/a n/a H3 Heating Output #3 Status (0=output
is OFF, 1=output is ON)
TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)
Read/
Write
BACnet
Object
Type
BACnet
Object
Inst
Descriptor Default Min Max Point Description
