Johnson Controls T9800 Series User Manual

T9800 series BACnet MS/TP Networked Thermostat Controller Technical Bulletin
Rev 1.4
7 | P a g e
RLY-2
Close Open
BO-1013
App:0~5
App:7,8,10~14,16~18
ALWAYS
RLY-3
Close Open
BO-1014
App:0~5
App:7~17
ALWAYS
RLY-4
Close Open
BO-1015
ALWAYS
NONE
NONE
RLY-5
Close Open
BO-1016
App:1~5
NONE
NONE
FRST-PRT
No
Yes
BV-1101
ALWAYS
ALWAYS
ALWAYS
TIO2-ESP
No
Yes
BV-1105
App:4
App:13
NONE
FH-FAN
No
Yes
BV-1108
App:3
App:12,16
NONE
MUTE
No
Yes
BV-1109
ALWAYS
ALWAYS
ALWAYS
ECM-RLY
No
Yes
BV-1110
NONE
App:9~17
NONE
ZN-T
0~55℃
AV-1201
ALWAYS
ALWAYS
ALWAYS
ZNT-SP
0~37℃
AV-1202
ALWAYS
ALWAYS
ALWAYS
OFFSET
-5～5℃
AV-1203
ALWAYS
ALWAYS
ALWAYS
ZN-H
0% ~ 100%
AV-1204
ALWAYS
ALWAYS
ALWAYS
UNOCC-CLG-
SP
22～32℃
AV-1206
ALWAYS
ALWAYS
ALWAYS
UNOCC-HTG-
SP
10～21℃
AV-1207
ALWAYS
ALWAYS
ALWAYS
FP-SP
0~20℃
AV-1208
ALWAYS
ALWAYS
ALWAYS
STG-DFFR
0 ~10 °C
AV-1211
App:3
App:12,16
NONE
SMPL-TM
1~99S
AV-1212
NONE
App:7,8,15~18
ALWAYS
PB
1~10
AV-1214
NONE
ALWAYS
KI
0~99
AV-1215
NONE
ALWAYS
HTRSS
1~5
AV-1217
App:0~6
App:9~14,17
NONE
DMP-OPEN-
TIME
0-99(75~174)
AV-1218
NONE
App:18
NONE
BL-TIMER
5~99
AV-1219
ALWAYS
ALWAYS
ALWAYS
TIMER-ON
0-1440
AV-1222
ALWAYS
ALWAYS
ALWAYS
TIMER-OFF
0-1440
AV-1223
ALWAYS
ALWAYS
ALWAYS
FAN-DELAY
0-99
AV-1224
App:0~5
ALWAYS
ALWAYS
MODE
Heat
Cool
Fan Only
Auto
MV-1302
ALWAYS
ALWAYS
ALWAYS
FAN-MODE
Low Speed
Med Speed
High Speed
Auto
MV-1303
App:0~5
ALWAYS
ALWAYS
OCC-S
Unoccupied
MV-1304
ALWAYS
ALWAYS
ALWAYS
