Johnson Controls TCD2B36S21S User Manual

Table 2: Physical and electrical data
Outdoor unit model TCD2B18S21S TCD2B24S21S TCD2B30S21S TCD2B36S21S TCD2B42S21S TCD2B48S21S TCD2B60S21S
Factory external
discharge muffler
No No No No No No No
HS kit required with
TXV
No No No No No No No
HS Kit Part Number
(S1-2SA067*****)
5
22006 22006 10106 10106 10106 10106 10106
Fan diameter (in.) 18 18 18 22 22 24 26
Fan motor type PSC PSC PSC PSC PSC PSC PSC
Fan motor rated HP 1/8 1/8 1/8 1/4 1/4 1/4 1/4
Fan motor rated load
(A)
0.7 0.7 0.7 1.3 1.3 1.3 1.3
Fan motor nominal
RPM
1075 1075 1075 850 850 850 850
Fan motor nominal
CFM
2150 2575 2575 2875 3350 3550 4300
Coil face area (sq. ft) 11.07 12.45 12.45 13.83 17.37 18.74 23.40
Coil rows deep 1 1 1 1 1 1 1
Coil fins per inch 23 23 23 23 23 23 23
Liquid refrigeration
piping outdoor unit
(field-installed)
3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor refrigeration
piping outdoor unit
(field-installed)
6
3/4 3/4 3/4 3/4 7/8 7/8
1 1/8
‡
Unit charge (lb-oz)
7
3-3 3-4 3-4 4-3 4-15 4-11 5-9
Charge (oz/ft) 0.62 0.62 0.62 0.62 0.67 0.67 0.75
Operating weight (lb) 120 135 130 150 195 200 230
Physical and electrical data notes
1. Rated in accordance with AHRI Standard 110-2012, utilization range A.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. Rotary compressor models are limited to an equivalent length of refrigeration piping of 100 ft
with no exceptions.
5. Refer to the Hard Start Kit Accessory Installation Manual for the hard start kit part number for
each model. The hard start kit is a field installed accessory.
6. For applications with non-standard vapor line sizes, refer to the Applications and accessories
section.
7. The unit charge is correct for the outdoor unit, smallest matched indoor unit, and 15 ft
of refrigerant tubing. For tubing lengths other than 15 ft, add or subtract the amount of
refrigerant, using the difference in actual refrigeration piping length (not the equivalent length)
multiplied by the per foot value.
‡ The adapter fitting must be field installed for the required 1 1/8 in. refrigeration piping.
Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase10
