Johnson Controls TCD2B36S21S - Performance Data - 4 Ton; Cooling Performance Data - 4 Ton

Table 35: Cool multiplier furnace - 3.5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
Z8ET080C16LMPS1S XAUC42E 1.00 0.96 0.96
Z8ET080C16LMPS1S XAUC48F 1.00 0.96 0.94
Z8ET100C16LMPS1S XAFC42E 1.00 0.97 0.98
Z8ET100C16LMPS1S XAFC48F 1.00 0.96 0.96
Z8ET100C16LMPS1S XAFD42E 1.00 0.97 0.96
Z8ET100C16LMPS1S XAFD48F 1.00 0.96 0.96
Z8ET100C16LMPS1S XAHC42E 0.99 0.95 0.97
Z8ET100C16LMPS1S XAHC48F 1.00 0.96 0.96
Z8ET100C16LMPS1S XAHD42E 0.99 0.95 0.97
Z8ET100C16LMPS1S XAHD48F 1.00 0.96 0.96
Z8ET100C16LMPS1S XAUC42E 1.00 0.97 0.98
Z8ET100C16LMPS1S XAUC48F 1.00 0.96 0.96
Z8ET100C20LMPS1S XAFC42E 1.00 0.96 0.96
Z8ET100C20LMPS1S XAFC48F 1.00 0.95 0.94
Z8ET100C20LMPS1S XAFD42E 1.00 0.96 0.96
Z8ET100C20LMPS1S XAFD48F 1.00 0.96 0.94
Z8ET100C20LMPS1S XAHC42E 0.99 0.94 0.95
Z8ET100C20LMPS1S XAHC48F 1.00 0.95 0.94
Z8ET100C20LMPS1S XAHD42E 1.00 0.96 0.96
Z8ET100C20LMPS1S XAHD48F 1.00 0.95 0.94
Z8ET100C20LMPS1S XAUC42E 1.00 0.96 0.96
Z8ET100C20LMPS1S XAUC48F 1.00 0.95 0.94
Z8ET120C20LMPS1S XAFC42E 1.00 0.97 0.98
Z8ET120C20LMPS1S XAFC48F 1.00 0.96 0.96
Z8ET120C20LMPS1S XAFD42E 1.00 0.97 0.96
Z8ET120C20LMPS1S XAFD48F 1.00 0.96 0.96
Z8ET120C20LMPS1S XAHC42E 0.99 0.95 0.97
Z8ET120C20LMPS1S XAHC48F 1.00 0.96 0.96
Z8ET120C20LMPS1S XAHD42E 0.99 0.95 0.97
Z8ET120C20LMPS1S XAHD48F 1.00 0.96 0.96
Z8ET120C20LMPS1S XAUC42E 1.00 0.97 0.98
Z8ET120C20LMPS1S XAUC48F 1.00 0.96 0.96
Performance data - 4 ton
See the following tables for performance and multiplier data for the TCD2B48S21S unit.
Condenser only performance data - 4 ton
Table 36: Condenser only performance data - 4 ton
Saturated suction
at compressor
Outdoor ambient temperature
Temperature Pressure 55°F 65°F 75°F 85°F 95°F 105°F 115°F
(°F) (psig) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
35 107 49.1 2.16 46.6 2.41 44.1 2.69 41.5 3.02 38.8 3.39 35.9 3.81 32.8 4.29
40 118 53.9 2.18 51.2 2.43 48.4 2.71 45.6 3.03 42.7 3.40 39.6 3.82 36.3 4.30
45 130 59.1 2.20 56.1 2.44 53.1 2.73 50.0 3.05 46.8 3.42 43.5 3.84 40.0 4.32
50 142 64.6 2.22 61.3 2.46 58.0 2.75 54.6 3.07 51.2 3.45 47.6 3.87 43.8 4.35
55 156 70.4 2.24 66.8 2.49 63.2 2.77 59.6 3.10 55.8 3.47 52.0 3.90 47.9 4.37
