Table 31: Cool multiplier furnace - 3 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
Z8ES120C20LMPS1 XAFD42E 1.00 0.96 0.96
Z8ES120C20LMPS1 XAHC36D 0.99 0.95 0.95
Z8ES120C20LMPS1 XAHC42E 0.99 0.95 0.95
Z8ES120C20LMPS1 XAHD42E 0.99 0.95 0.95
Z8ES120C20LMPS1 XAUC42E 1.00 0.96 0.96
Z8ES120C20SMPS1S XAFC36D 0.99 0.95 0.95
Z8ES120C20SMPS1S XAFC42E 1.00 0.96 0.96
Z8ES120C20SMPS1S XAFD42E 1.00 0.96 0.96
Z8ES120C20SMPS1S XAHC36D 0.99 0.95 0.95
Z8ES120C20SMPS1S XAHC42E 0.99 0.95 0.95
Z8ES120C20SMPS1S XAHD42E 0.99 0.95 0.95
Z8ES120C20SMPS1S XAUC42E 1.00 0.96 0.96
Z8ES130D20LMPS1 XAFD42E 1.02 1.02 0.97
Z8ES130D20LMPS1 XAHD42E 1.01 1.00 0.97
Z8ES130D20SMPS1S XAFD42E 1.02 1.02 0.97
Z8ES130D20SMPS1S XAHD42E 1.01 1.00 0.97
Z8ET080B12LMPS1S XAFB36D 1.00 1.00 1.00
Z8ET080B12LMPS1S XAFB36E 1.01 1.01 1.01
Z8ET080B12LMPS1S XAFC36D 1.00 1.01 1.00
Z8ET080B12LMPS1S XAFC42E 1.01 1.02 0.99
Z8ET080B12LMPS1S XAHC36D 1.00 1.00 1.00
Z8ET080B12LMPS1S XAHC42E 1.01 1.01 1.01
Z8ET080B12LMPS1S XAUB36D 1.00 1.00 1.00
Z8ET080B12LMPS1S XAUC42E 1.01 1.02 0.99
Z8ET080C16LMPS1S XAFC36D 1.00 0.97 0.94
Z8ET080C16LMPS1S XAFC42E 1.01 0.97 0.94
Z8ET080C16LMPS1S XAFD42E 1.01 0.98 0.94
Z8ET080C16LMPS1S XAHC36D 1.00 0.97 0.96
Z8ET080C16LMPS1S XAHC42E 1.01 0.97 0.96
Z8ET080C16LMPS1S XAHD42E 1.01 0.97 0.96
Z8ET080C16LMPS1S XAUC42E 1.01 0.97 0.94
Z8ET100C16LMPS1S XAFC36D 1.00 0.98 0.96
Z8ET100C16LMPS1S XAFC42E 1.01 0.99 0.96
Z8ET100C16LMPS1S XAFD42E 1.01 1.00 0.96
Z8ET100C16LMPS1S XAHC36D 1.00 0.98 0.96
Z8ET100C16LMPS1S XAHC42E 1.01 0.99 0.96
Z8ET100C16LMPS1S XAHD42E 1.01 0.99 0.96
Z8ET100C16LMPS1S XAUC42E 1.01 0.99 0.96
Z8ET100C20LMPS1S XAFC36D 0.99 0.95 0.93
Z8ET100C20LMPS1S XAFC42E 1.00 0.96 0.94
Z8ET100C20LMPS1S XAFD42E 1.00 0.96 0.96
Z8ET100C20LMPS1S XAHC36D 0.99 0.95 0.95
Z8ET100C20LMPS1S XAHC42E 0.99 0.94 0.95
Z8ET100C20LMPS1S XAHD42E 0.99 0.95 0.95
Z8ET100C20LMPS1S XAUC42E 1.00 0.96 0.94
Z8ET120C20LMPS1S XAFC36D 1.01 1.04 0.99
Z8ET120C20LMPS1S XAFC42E 1.02 1.05 0.99
Z8ET120C20LMPS1S XAFD42E 1.02 1.05 0.99
Z8ET120C20LMPS1S XAHC36D 1.01 1.04 0.99
Z8ET120C20LMPS1S XAHC42E 1.02 1.05 0.99
Z8ET120C20LMPS1S XAHD42E 1.02 1.05 0.99
Z8ET120C20LMPS1S XAUC42E 1.02 1.05 0.99
