TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
15
Table 4: Installer Configuration Menu (Part 1 of 6)
Parameter
Appearing
on Display
Description and Default Selection Options
Pswrd Sets the protective access
password to prevent unauthorized
access to the Installer Configuration
Menu.
Default: 0
Note: The default setting does not
lock out access to the Installer
Configuration Menu.
Range: 0 to 1,000
Com addr MS/TP address at the thermostat
controller; coincides with the
address assigned at the supervisory
controller.
Default: 254
Range: 004 to 127
BI1 Configuration of Binary Input 1.
Default: None
(None): No function is associated with an input.
(Rem NSB): Remote Night Setback (NSB) via a time clock input, an
occupancy sensor, or from a voltage-free contact.
Contact open = Occupied; contact closed = Unoccupied.
(MotionNO*): Temporary occupancy request via a motion detector
input. Contact open = Unoccupied. When the contact closes, the
thermostat controller goes into the occupied mode for a specified
TOccTime. Once the TOccTime begins, the thermostat controller
remains in the occupied mode if the contact is open, until the
TOccTime expires.
(MotionNC*): Temporary occupancy request via a motion detector
input. Contact closed = Unoccupied. When the contact opens, the
thermostat controller goes into the occupied mode for a specified
TOccTime. Once the TOccTime begins, the thermostat controller
remains in the occupied mode if the contact is closed, until the
TOccTime expires.
(Window**): Cancels the thermostat controller heating or cooling
action when a window is open. A Window alarm is displayed
indicating that the window needs to be closed to resume heating or
cooling.
* These settings disable any local override function.
** When this setting is selected, the heating and or cooling outputs
are enabled only when the contact is closed. If the fan is set to Auto,
it is enabled only when the contact is closed. If the fan is set to On, it
is not affected by this setting.
