TEC2664Z-3 BACnet® MS/TP Rooftop Controller for Stand-Alone and Networked Zoning Systems
Installation Instructions
24
Zoning Control System Components
Accessories
All the accessories in Table 6 include mounting
hardware; contact the nearest Johnson Controls
representative to order any of these parts.
Note: Review the technical specifications of the
accessories prior to their use in an application.
Repair Information
If the TEC2664Z-3 Rooftop Controller fails to operate
within its specifications, refer to the TEC Zoning
Control System for Stand-Alone and BACnet MS/TP
Networked Applications Technical Bulletin
(LIT-12011682) for troubleshooting details. For a
replacement rooftop controller, contact the nearest
Johnson Controls representative.
Table 5: TEC Zoning Control System
Code Number Description
TEC2647Z-3 Zone Controller for Proportional Zone Damper, On/Off, or Proportional Reheat Control
TEC2647Z-3+PIR Zone Controller with Occupancy Sensor for Proportional Zone Damper, On/Off, or Proportional Reheat
Control
TEC2664Z-3 Rooftop Controller for Control of Up to Two Stages of Heating and Two Stages of Cooling in Rooftop,
Proportional Bypass Damper, Fan, and Zone Demand Strategies
Table 6: Accessories (Order Separately)
Code Number Description
SEN-600-1 Remote Inside Air Temperature Sensor
TE-6361M-1
1
Duct Mount Air Temperature Sensor (Metal Enclosure)
TE-6363P-1
1, 2
Outside Air Temperature Sensor (Plastic Enclosure)
SEN-600-4 Remote Inside Air Temperature Sensor with Occupancy Override and LED
DPT2650-005D-AB Duct Static Pressure Transmitter, 24 VAC Power, 0 in. W.C./0 Pa to 5 in. W.C./1,245 Pa Input,
0to5VDCOutput
MS-BACEOL-0 RS485 End-of-Line Terminator
1. Additional TE-636xx-x Series 10k ohm Johnson Controls Type II Thermistor Sensors are available; refer to the
TE-6300 Series Temperature Sensors Product Bulletin (LIT-216320) for more details.
2. An outside air temperature sensor is recommended to allow the H lock and C lock parameters of the rooftop controller to
discontinue heating or cooling operation in response to the outside air temperature. If an outside air temperature sensor is
not installed, an ambiguous outside air temperature displays on the zone controller unless its MenuScro parameter is set
to off.
