TEC3000 Series Networked and Wireless Single- or Two-stage Economizer
Thermostat Controllers technical specifications
Table 10: TEC3000 Series Networked and Wireless Single- or Two-Stage Economizer Thermostat Controllers
Specification Description
Power requirements 19 VAC to 30 VAC, 50/60 Hz, 4 VA at 24 VAC nominal, Class 2 or safety extra-low voltage
(SELV)
USB port power rating 120 mA to 250 mA current draw supported
Relay contact rating 19 VAC to 30 VAC, 1.0 A maximum, 15 mA minimum, 3.0 A in-rush, Class 2 or SELV
Binary inputs Dry contact across terminal COM to terminals BI1 or BI2
Analog inputs Nickel, platinum, A99B, 2.25k ohm NTC, 10k ohm NTC, 10k ohm NTC Type 3 across terminal
COM to terminals R SEN
Temperature sensor type Local digital sensor
Wire size 18 AWG (1.0 mm diameter) maximum, 22 AWG (0.6 mm diameter) recommended
For wired models: Up to 100 devices maximum for each Metasys Supervisory Engine; 4,000
ft (1,219 m) maximum cable length. Refer to the MS/TP Technical Bulletin for the Metasys,
FX, or Verasys
®
system installed.
MS/TP network guidelines
For wireless models: Up to 100 devices maximum for each Metasys Supervisory Engine
Wireless band (for wireless models) Direct-sequence spread-spectrum 2.4 GHz ISM bands
TEC30xx-1x-000
compatible with
ZFR182x Pro Series
10 mW maximumTransmission power (for
wireless models)
TEC31xx-1x-000
compatible with
ZFR183x Pro Series
100 mW maximum
TEC30xx-1x-000
compatible with
ZFR182x Pro Series
50 ft (15.2 m) recommended indoor
250 ft (76.2 m) line of sight, maximum
Transmission range (for
wireless models)
TEC31xx-1x-000
compatible with
ZFR183x Pro Series
250 ft (76.2 m) recommended indoor
1000 ft (304.8 m) line of sight, maximum
Backlit display -40.0°F/-40.0°C to 122.0°F/50.0°C in 0.5° increments
Heating control 40.0°F/4.5°C to 90.0°F/32.0°C
Temperature range
Cooling control 54.0°F/12.0°C to 100.0°F/38.0°C
Accuracy Temperature ±0.9F°/±0.5C° at 70.0°F/21.0°C typical calibrated
Minimum deadband 2F°/1C° between heating and cooling
Occupancy sensor motion detection
(occupancy sensing models)
Minimum of 94 angular degrees up to a distance of 15 ft (4.6 m); based on a clear line of
sight
Operating 32°F to 122°F (0°C to 50°C); 95% RH maximum, noncondensingAmbient conditions
Storage -4°F to 122°F (-20°C to 50°C); 95% RH maximum, noncondensing
BACnet
International
BACnet Testing Laboratories
™
(BTL) 135-2001 Listed BACnet Advanced Application
Controller (B-AAC)
UL Listed, File E27734, CCN XAPX, Under UL60730
Networked models: FCC Compliant to CFR 47, Part 15, Subpart B, Class B
United States
Wireless models: Transmission complies with FCC Part 15.247 regulations for low power
unlicensed transmitters; transmitter identification FCC ID: OEJ-WRZRADIO (ZFR182x), OEJ-
ZFRRADIO (ZFR183x)
UL Listed, File E27734, CCN XAPX7, Under E60730
Networked models: Industry Canada, ICES-003
Compliance
Canada
Wireless models: Industry Canada (IC) RSS-210;
Transmitter identification ZFR1810-1: IC ID: 279A-WRZRADIO (ZFR182x), 279A-ZFRRADIO
(ZFR183x)
Europe (for
networked models
only)
CE Mark – Johnson Controls declares that this product is in compliance with the essential
requirements and other relevant provisions of the EMC Directive and the RoHS Directive.
TEC3000 Series Networked and Wireless Single- or Two-stage Economizer Thermostat Controllers Quick Start Guide 29

Johnson Controls TEC3030 Specifications

General

Brand	Johnson Controls
Model	TEC3030
Category	Controller
Language	English
