TEC3000 Series Proportional Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
14
Fan Overrides for
Single-speed Fans
On
Auto
Quiet
Adjusts the fan override between On, Auto, and Quiet for single-speed fans.
Fan Overrides for
Variable-speed Fans
On
Auto
Quiet
Adjusts the fan override between On, Auto, and Quiet for variable-speed fans.
Fan Overrides for
Multi-speed Fans
Low
Medium
High
Auto
Quiet
Adjusts the fan override between Low, Medium, High, Auto, and Quiet for
multi-speed fans.
Home
Returns the display to the main home screen.
Back
Returns to the previous screen.
Save
Saves the current configuration and parameter settings.
Delete
Deletes the scheduled event.
Table 3: Touchscreen Icons (Part 2 of 3)
Icon Icon Name Description
