Johnson Controls XAF Series User Manual

Table 1: Dimensions - XAF upflow or downflow full-cased coil
Dimensions
Height Width Opening widths
Refrigerant connections line size
Models
A (in.) B (in.) C (in.) D (in.) Liquid (in.) Vapor (in.)
XAFA18AXXN1* 19 1/2 14 1/2 13 1/2 13 1/2
XAFA18ABAN1 19 1/2 14 1/2 13 1/2 13 1/2
XAFB18AXXN1* 19 17 1/2 16 1/2 16 1/2
XAFB18ABAN1 19 17 1/2 16 1/2 16 1/2
XAFA24BXXN1* 21 5/8 14 1/2 13 1/2 13 1/2
XAFA24BBAN1 21 5/8 14 1/2 13 1/2 13 1/2
XAFB24BXXN1* 23 17 1/2 16 1/2 16 1/2
XAFB24BBAN1 23 17 1/2 16 1/2 16 1/2
XAFB30CXXN1* 25 5/8 17 1/2 16 1/2 16 1/2
XAFB30CBAN1 25 5/8 17 1/2 16 1/2 16 1/2
XAFC30CXXN1* 23 21 20 20
XAFC30CBAN1 23 21 20 20
XAFA30DXXN1* 25 1/2 14 1/2 13 1/2 13 1/2
XAFA30DBAN1 25 1/2 14 1/2 13 1/2 13 1/2
XAFB36DXXN1* 25 5/8 17 1/2 16 1/2 16 1/2
XAFB36DBAN1 25 5/8 17 1/2 16 1/2 16 1/2
XAFB36DBCN1 25 5/8 17 1/2 16 1/2 16 1/2
XAFC36DXXN1* 23 21 20 20
XAFC36DBAN1 23 21 20 20
XAFC36DBCN1 23 21 20 20
3/4
XAFB36EXXN1* 25 5/8 17 1/2 16 1/2 16 1/2
XAFB36EBCN1 25 5/8 17 1/2 16 1/2 16 1/2
XAFC42EXXN1* 25 21 20 20
XAFC42EBCN1 25 21 20 20
XAFD42EXXN1* 25 24 1/2 23 1/2 23 1/2
XAFD42EBCN1 25 24 1/2 23 1/2 23 1/2
XAFC48FXXN1* 27 21 20 20
XAFC48FBAN1 27 21 20 20
XAFC48FBCN1 27 21 20 20
XAFD48FXXN1* 27 24 1/2 23 1/2 23 1/2
XAFD48FBAN1 27 24 1/2 23 1/2 23 1/2
XAFD48FBCN1 27 24 1/2 23 1/2 23 1/2
XAFC60GXXN1* 33 21 20 20
XAFC60GBAN1 33 21 20 20
XAFC60GBCN1 33 21 20 20
XAFD60GXXN1* 32 3/4 24 1/2 23 1/2 23 1/2
XAFD60GBAN1 32 3/4 24 1/2 23 1/2 23 1/2
XAFD60GBCN1 32 3/4 24 1/2 23 1/2 23 1/2
XAFC60HXXN1* 37 1/4 21 20 20
XAFC60HBCN1 37 1/4 21 20 20
XAFD60HXXN1* 37 1/4 24 1/2 23 1/2 23 1/2
XAFD60HBCN1 37 1/4 24 1/2 23 1/2 23 1/2
XAFD60JXXN1* 32 3/4 24 1/2 23 1/2 23 1/2
XAFD60JBCN1 32 3/4 24 1/2 23 1/2 23 1/2
3/8
7/8
Note:
• * denotes coil models available with a factory installed thermal expansion valve (TXV).
• Refrigerant line sizes may require larger lines for extended line lengths. Refer to application data part number
247077.
• The adapter fitting must be field installed for any refrigeration piping sizes not shown in the table.
• Refer to the Technical Guide for the outdoor unit for the proper refrigeration piping size.
Installation Manual: XAF, XAH, and XAU Series - Full Cased and Uncased Coils for Cooling and Heat Pumps8
