Johnson Controls YORK YMC2 Wiring Diagram

JOHNSON CONTROLS
2
FORM 160.78-PW3 (1110)
This equipment is a relatively complicated apparatus.
During installation, operation maintenance or service,
individuals may be exposed to certain components or
conditions including, but not limited to: refrigerants,
materials under pressure, rotating components, and
both high and low voltage. Each of these items has the
potential, if misused or handled improperly, to cause
bodily injury or death. It is the obligation and respon-
sibility of operating/service personnel to identify and
recognize these inherent hazards, protect themselves,
and proceed safely in completing their tasks. Failure
to comply with any of these requirements could result
in serious damage to the equipment and the property in
IMPORTANT!
READ BEFORE PROCEEDING!
GENERAL SAFETY GUIDELINES
which it is situated, as well as severe personal injury or
death to themselves and people at the site.
This document is intended for use by owner-authorized
operating/service personnel. It is expected that this in-
dividual posseses independent training that will enable
them to perform their assigned tasks properly and safe-
ly. It is essential that, prior to performing any task on
this equipment, this individual shall have read and un-
derstood this document and any referenced materials.
This individual shall also be familiar with and comply
with all applicable governmental standards and regula-
tions pertaining to the task in question.
CHANGEABILITY OF THIS DOCUMENT
In complying with Johnson Controls’ policy for contin-
uous product improvement, the information contained
in this document is subject to change without notice.
While Johnson Controls makes no commitment to up-
date or provide current information automatically to
the manual owner, that information, if applicable, can
be obtained by contacting the nearest Johnson Controls
Service office.
Operating/service personnel maintains the responsi-
bility of the applicability of these documents to the
competitive equipment the kit is installed on. If there
is any question regarding the applicability of these
documents, the technician should verify whether the
equipment has been modified and if current literature
is available with the owner of the equipment prior to
performing any work on the chiller.
External wiring, unless specied as an
optional connection in the manufacturer’s
product line, is not to be connected inside
the OptiView cabinet. Devices such as
relays, switches, transducers and controls
and any external wiring must not be in-
stalled inside the micro panel. All wiring
must be in accordance with Johnson Con-
trols’ published specications and must
be performed only by a qualied electrician. Johnson
Controls will NOT be responsible for damage/problems
resulting from improper connections to the controls
or application of improper control signals. Failure
to follow this warning will void the manufacturer’s
warranty and cause serious damage to property or
personal injury.

Johnson Controls YORK YMC2 Specifications

General

Brand	Johnson Controls
Model	YORK YMC2
Category	Chiller
Language	English
