Johnson Controls YVAHP036B21S User Manual

OPTIONAL PARTS
TC-16001-rev.5
3-9
3.6 Snow Protection Hood
This Snow Protection Hood prevents snow from entering the outdoor unit and prevents strong winds from
blowing against the heat exchanger.
(1) Full Type: ASG-SP11FCS2, ASG-SP11BAS2, ASG-SP11LAS2
15-3/4
(400)
A
A
< Air Outlet Hood >
8 x φ1/4 (φ7)
23-1/4 (590)
11-5/16
(287)
10-7/8
(277)
<25-9/16 (650)> <26 (660)>
52-3/4 (1340)
4 x φ5/16 (φ8)
(Hole for Securing
Screw to Prevent
Overturning)
1
2
2
3
4
5
5
6
9
8
7
1
<18-1/8 (460)>
<13-3/8 (340)>
<12-5/8 (320)>
30-7/8 (785)
<30-1/16 (763)>
51-3/16 (1300)
11-13/16
(300)
<12-5/8 (320)>
<18-7/8 (480)>
<12-5/8 (320)>
2 x φ5/16 (φ8)
(Hole for Securing
Screw to Prevent
Overturning)
1
< Rear Air Inlet Hood >
2
3
4
5
< Left Air Inlet Hood >
9-13/16
(250)
12-5/8
(320)
51-3/16 (1300)
20-1/16
(510)
<12-5/8 (320)>
11-7/16
(290)
1/2
(12)
Enlarged View of
A
(Securing Hole)
1/4 (7)
R
φ
9/16 (
φ
15)
1
4 x φ1/4 (φ7) x 12
(Long Hole)
3
4
2
5
No. Part Name Qty.
1
Right Plate 1
2
Left Plate 1
3
Front Plate (Upper) 1
4
Front Plate (Lower) 1
5
Assembling Screw
(Accessory)
14
No. Part Name Qty.
1
Right Plate 1
2
Left Plate 1
3
Front Plate (Upper) 1
4
Front Plate (Lower) 1
5
Assembling Screw
(Accessory)
12
No. Part Name Qty.
1
Right Plate 2
2
Left Plate 2
3
Front Plate for Upper (Upper) 1
4
Front Plate for Lower (Upper) 1
5
Front Plate (Lower) 2
6
Installing Stay 1
7
Securing Plate for Upper 1
8
Securing Plate for Lower 1
9
Assembling Screw (Accessory) 33
inch (mm)
˂ ˃: Installation Dimension
