Johnson Controls ZU Seies - Roof Curb Components; ZUT06 through T12 Roof Curb; ZUT06 through T12 Transition Roof Curb

5566218-TIM-B-1118
16 Johnson Controls Ducted Systems
Figure 15: ZUT06 through T12 roof curb
Figure 16: ZUT06 through T12 transition roof curb
8 or 14
50-1/2
30
20
20
80-5/8
6
A
B
E
G
D
F
C
76-5/8
94
50-1/2
30-1/2
64-1/4
59-1/4
10
23
4
26
80-5/8
B
A
C
E
D
Roof curb components
Item Description
A Return air
B Supply air
C Right side of the unit
D Front side of the unit
E 2 typ.
F Insulated deck under the condenser section
G Insulated deck under the compressor section
