12 - General Information
ENGINE SPECIFICATIONS
9.9, 10, 15 Models
Displacement 15.6 cu. in. (256 cc)
Engine Type Two-Cycle, In-line, 2 Cylinder
Full Throttle Operating Range 9.9, 10 – 5000 to 6000 RPM
15 – 5500 to 6500 RPM
Power
(1)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046, and NMMA.
9.9 – 9.9 HP (7.4 kw) @ 5500 RPM
10 – 10 HP (7.5 kw) @ 5500 RPM
15 – 15 HP (11.2 kw) @ 6000 RPM
Idle RPM in Gear
(2)
(2) Emission Control Information
700 ± 50
Ignition Timing – Idle
(2)
W.O.T.
Not Adjustable
Not Adjustable
Exhaust Emission Control
(2)
System per SAE J1930
EM (Engine Modification)
Fuel Requirements
(2)
87 Pump Posted AKI (89 RON) – Refer to Fuel and Oil
Fuel/Oil Ratio 50:1
Starting R, RL, RH, RHL – Rope start
Battery, Minimum 360 CCA (465 MCA)
OR 50 ampere-hour, 12 volts
Spark Plug
(2)
Extended Low Speed Operation
Torque
Refer to ECI Label
9.9 only – QL86C @ 0.030 in. (0.8 mm) Gap
18 to 21 ft. lbs. (24 to 28 N
·m)
AC Lighting
(3)
(3) Available as optional kit
60 watts AC @ 12 volts
Gearcase –Lubricant
Capacity
Evinrude/Johnson Ultra-HPF™
gearcase lubricant
9 fl. oz. (260 ml)
Propeller
(4)
(4) Not supplied in all marketing areas
9.9 – 9 1/2 x 10 in. (24.1 x 25.4 cm)
10, 15 – 9 x 11 in. (22.9 x 27.9 cm)
Fuel Tank – Capacity 9.9 – 3.2 U.S. Gallons (12.1 Liters)
10, 15 – 6 U.S. Gallons (22.7 Liters)
Weight R, RH – 74 lbs. (33.6 kg)
RL, RHL – 77 lbs. (34.9 kg)
Transom Height R, RH – 14 1/2 to 15 in. (36.8 to 38.1 cm)
RL, RHL – 19 1/2 to 20 in. (49.5 to 50.8 cm)
Sound at Driver’s Ear
(L
pA
) ICOMIA 39.94
86.0 dB(A)
Vibration at Tiller (arms) Less than 2.5 m/s
2
