40 - Maintenance
AC LIGHTING
1. Sleeve
2. Electrical tape covering connection
3. Light bulb
Y – Yellow wire
YG – Yellow/Grey wire
YB – Yellow/Blue wire
Some models have an AC (alternating current)
lighting system for operating lights on a boat. An AC
lighting system is available as an optional kit.
IMPORTANT: Alternating current is generated and
MUST NOT be connected directly to a battery. For
battery charging, install a battery charging kit. See
your DEALER.
Various combinations of light bulbs can be used.
Use 12-volt bulbs of wattage sizes indicated on the
diagram.
Follow the illustration for proper installation of
wires.
2
1
3
