Johnston CN101 - Electrical System

Chapter - Electrical System
CHAPTER
3
Electrical System
3:1
Table of Contents
Section Page
Electrical Circuit Key 3 : 3
Ignition Switch Circuit 3 : 4
Rear Lighting System Circuit 3 : 5
Indicators Circuit 3 : 6
Front Lighting System Circuit 3 : 7
Rear Camera Circuit 3 : 8
Windscreen Wiper Circuit 3 : 9
Heater & Air Conditioning Circuit 3 : 10
Water System 1 Circuit 3 : 11
Water System 2 Circuit 3 : 12
Engine Starter Circuit 3 : 13
Sensors Circuit 3 : 14
ECU Controller Circuit 3 : 15
Transmission Circuit 3 : 16
Side Brush Positioning Circuit 3 : 17
Suction Circuit 3 : 18
Side Brush Sweeping Control Circuit 3 : 19
Hydraulics & Water Recirculation Circuit 3 : 20
Hopper & Heating Circuit 3 : 21
4WS Circuit 3 : 22
