CN101 - Maintenance
8. Ret the cover panel over the hydraulic controls and top up the hydraulic oil as required – see
operator’s gu for further details.
9. Lower the hopper and test drive the vehicle to ensure correct operation.
Figure One
Rear steering cylinder extended to its
maximum stroke.
Figure Two
Installation of tee piece and test point to
port HB of the 4WS hydraulic valve block.
Figure Three
Test hose connected to test point at port HB
on the 4WS hydraulic valve block.
