Johnston Sweepers Limited
Chapter - Optional Equipment
Page Issue 01
OG
4:7
V Range 501 ● 651 ● 801 - Operator’s Guide
HandLanceDetergentInjection
Note:
This option is only available with Supawash.
M02OG-097
A
B
C
D
Supawash Operation - Continued
If the vehicle is being used exclusively for street washing (no sweeping), the water tank capacity
can be extended after firstly thoroughly washing out the body and removing the plug in the body of
the floor and installing the optional filter assembly.
The body can be filled with water using the offside hydrant filler (when the machine is equipped with
the optional re-circulating water) or via the side access doors to the level of the water tank overflow,
thereby extending your on station time.
Note:
The plug must be replaced before sweeping or dirt will enter the water tanks and cause
damage/blockages to the water pumps.
HAND LANCE DETERGENT INJECTION
Operation
Fill the detergent can (A) with detergent.
Operate the detergent injection control knob (D) at the end of the hand lance by turning
it clockwise to position (ii).
Pressing the hand lance trigger will allow water to spray from the jet and outer cone of
(D). This allows the detergent to be mixed with the water.
The rate of the detergent mix is controlled by valve (C). The detergent will take a few
seconds to appear at the lance due to the length of hand lance hose. To stop the
detergent turn the knob (D) counterclockwise to position (i) which returns the hand lance
to the normal fan jet.
(A) 6 litre detergent can
(B) Filler port
(C) Detergent mix control
(D) Hand lance control
All Copyright and rights are the property of Johnston Sweepers Ltd
