Install Using LATCH:
INSTALL USING ONLY ONE METHOD.
NEVER install using BOTH seat belt and LATCH.
1 - Insert LATCH guides to help with installation.
2 - Press the LATCH rotate button (1) on either side first to turn
the LATCH connectors down (2).
3 - Line up the LATCH connectors with the LATCH guides, and
then click both LATCH connectors onto the LATCH anchor bars.
4 - There should be two audible clicks, and the colors of the
indicators on both LATCH connectors should be completely green.
Check to make sure the child restraint is securely installed by
pulling on both LATCH connectors.
(Install Using LATCH continued on PG. 40)
