Joie mint latch - To Remove LATCH

40 41
To Remove LATCH:
1 - To remove the child restraint, squeeze the LATCH release
lever on the back of the infant carrier and pull the child restraint
away from the LATCH anchor bars.
2 - Press the LATCH rotate buttons to fold LATCH connectors back
to the storage position. Remove child restraint from the vehicle.
1
2
1
2
2
Install Using LATCH: (cont.)
5 -
Make sure the LEVEL LINE on the restraint label is LEVEL
WITH THE GROUND. Rotate the LATCH by pressing the LATCH
rotate button (1) to adjust the recline of the seat (2).
5
1
2
Check Install!
Blue level line must be level with ground.
LATCH connectors are properly attached and show
green on the indicators.
Child restraint should be stable and not move side to
side more than 1 inch (2.5 cm).
