Removing Canopy/Fabric: (cont.)
7 - Remove the crotch pad, then thread the buckle and crotch
belt through the bottom slot of both the infant insert and seat pad.
8 - Remove the infant insert.
9 - Disconnect the harness by referring to “Adjusting Harness
Height” on PG. 30.
10 - Starting from the bottom, lift the seat pad to remove it from
the child restraint shell.
11 - Carefully slide the lap belt guides through the opening in the
fabric. Continue lifting the seat pad until it’s completely removed.
To re-assemble, follow these steps in reverse order.
7 8
11
9
10
