Jonker Sailplanes JS-3 Rapture User Manual

JS-MD 3
Aircraft Flight Manual
MD10-AFM-00-001
Issue: 01
Rev. 00
Rev. Date: 14-Feb-20
Page 7-15
Landing gear system
The landing gear handle is located on the right-hand side of the cockpit
and labelled as illustrated in Figure 7.3-1. Pulling the handle backwards
retracts the landing gear and pushing it forward extends the landing gear.
The handle is rotated firmly clockwise to lock the landing gear in the
extended and retracted position.
If a retractable tail wheel is fitted, the retractable tail wheel is extended
mechanically with the main gear. When the main wheel is retracted, a
spring retracts the tail wheel.
Figure 7.3-1
