Jonker Sailplanes JS-3 Rapture User Manual

JS-MD 3
Aircraft Flight Manual
MD10-AFM-00-001
Issue: 01
Rev. 00
Rev. Date: 14-Feb-20
Page 7-17
Pneumatic system
The aircraft pneumatic system consists of:
• Static (P
STAT
) piping for the ASI and altimeter
• Dynamic (P
TOT
) piping for the ASI
• Static piping for the variometer from fin probe
• Total energy (TE) piping from the fin probe
The pneumatic piping is colour coded as follows:
Pneumatic piping
Colour
Static for the ASI and Altimeter
Blue
Dynamic for the ASI
Green
Static for the electronic flight computer from the
multi-probe
Transparent/White
Total energy from the fin probe
Red
Mechanical variometer capacity
Yellow
Table 7.5-1
Figure 7.5-2 gives a schematic of the instrument layout.
NOTE: The ASI must use the static sources located in the rear
of the fuselage tube. The airspeed calibration values are
based on these static port readings.
NOTE: Static ports located in the rear of the fuselage tube are
marked with a red ring and must be kept unobstructed
to ensure correct ASI readings.
