Wing rigging
1. Ensure that the red rubber water drain plugs are inserted in the
wing roots in front of the forward lift pin.
2. Clean and grease all pins and matching bushes, including the
main pins.
3. Unlock both airbrakes using the airbrake locking wrench.
4. Set the flap handle in flap position 2 or position 3 and the control
stick to the centre position.
5. Close the water valve in the cockpit.
6. Ensure that the self-aligning bushes in the main ribs of both
wings are aligned correctly.
7. Ensure that the drain plugs on the root ribs of the main wing at
the leading edge are installed
8. Insert the right spar end into the fuselage with the flaperon in the
neutral position and the dihedral angle approximately correct.
9. Insert the left spar end into the fuselage, also with the flaperon
in the neutral position and the dihedral angle as such to slide into
the self-aligning bush of the other wing.
10. Insert the main pin when the wings are fully in.
11. Secure the main pin by rotating the pin into the spring- loaded
lock pins.
12. Ensure that the tail is lifted off the ground with sufficient
clearance for the tail wheel to extend. Extend and lock the
landing gear and lower the aircraft onto the wheel. Ensure that
the 18 m tip rubber water drain plugs are inserted (18 m wing
tips roots on junction rib).
13. Pull the wingtip locking lever fully back and slide the wingtip
beam into the main wing. Push the wingtip locking lever forward
