JS-MD 3
Aircraft Flight Manual
MD10-AFM-00-001
Issue: 01
Rev. 00
Rev. Date: 14-Feb-20
Page 7-2
The wheel brake is activated by squeezing a trigger on the control stick
illustrated in Figure 7.2-1.
Figure 7.2-1
Rudder
The rudder is controlled by the rudder pedals in the front section of the
fuselage. Pushing either pedal deflects the rudder in the desired
direction.
The rudder pedals fore and aft position is adjustable to accommodate
different size pilots. The ergonomic controller on the right-hand side of
the cockpit is used to make adjustments either on the ground or during
flight.
CAUTION: If there is a malfunction of the rudder pedals in the form
of an uncommanded movement the “Ergo” fuse on the
instrument panel should be pulled in order to disconnect
the power from the rudder actuator circuit.
