115
Tools
9.
9
Contents
Oil pump 116
Generator 116
Clutch 117
Vibration damper 117
Crankshaft 118
Ball bearing 118
Sealing ring 119
Cylinder and piston 120
Ignition system 120
Crankcase 121
Tightness testing 122
Chain brake 122
Fuel pick-up 122
Workshop equipment 123
