Jonsered CS 2145 User Manual

38 – English
TECHNICAL DATA
´®z+R2r¶62¨
´®z+R2r¶62¨
Bar and chain combinations
The following combinations are CE approved.
Saw chain filing and file gauges
Bar Chain
Length, inch Pitch, inch Gauge, mm Max. nose radius Type Length, drive links (no.)
13 0,325 1,3 10T Jonsered H30 56
15 0,325 10T 64
16 0,325 10T 66
18 0,325 10T 72
13 0,325 1,5 10T Jonsered H25 56
15 0,325 10T 64
16 0,325 10T 66
18 0,325 10T 72

Jonsered CS 2145 Specifications

General

Engine Power	2.1 kW
Weight	4.9 kg
Oil Tank Volume	0.26 liters
Bar Length	13-18 inches
Chain Pitch	0.325 inches
Chain Gauge	0.05 inches
Cylinder Displacement	45 cm³
