40 – English
TECHNICAL DATA
Technical data
CS 2188
Engine
Cylinder volume, cu.in/cm
3
5,4/88
Cylinder bore, inch/mm 2,2/55
Stroke, inch/mm 1,5/37
Idle speed, rpm 2700
Power, kW/ rpm 4,8/9600
Ignition system
Manufacture SEM
Type of ignition system CD
Spark plug NGK BPMR 7A/ Champion RCJ 7Y
Electrode gap, inch/mm 0,02/0,5
Fuel and lubrication system
Manufacturer of carburetor Walbro
Carburetor type WJ 116
Fuel tank capacity, US pint/litre 1,9/0,9
Oil pump capacity at 9,000 rpm, ml/min 6-24
Oil tank capacity, US pint/litre 1,06/0,5
Type of oil pump Automatic
Weight
Chain saw without bar or chain, empty tanks, lb/kg 15,6/7,1
Chain/bar
Recommended bar lengths, inch/cm 18-28”/46-71
Usable cutting length, inches/cm 17-27”/43-69
Pitch, inch/mm 3/8" /9,52
Thickness of drive links, inch/mm 0,058/1,5
Drive sprocket type/teeth Rim/7
Chain speed at max. power, m/sec 21,4
