Jonsered LT2216A2 - Chassis and Enclosures

7
5 532 41 20-69 Dash
14 532 42 69-83 Hood
15 532 18 97-54 Lens LH
18 532 19 29-15 Grille
25 532 18 97-55 Lens RH
34 532 19 61-25 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 44 12-66 Fender
52 873 68 05-00 Nut Crown Lock 5/16
68 817 49 05-08 Screw THDROL 5/16-18 x 1/2
130 532 19 16-11 Screw
137 532 18 49-21 Bumper Dash
138 532 40 97-30 Cupholder
150 532 18 43-22 Air Duct
151 532 40 78-07 Bracket Pivot
152 532 19 95-35 Shield Browning
161 532 41 20-72 Window Fuel
162 532 14 24-32 Screw 1/4 x 1/2
165 532 19 68-26 Support Tank Rear
175 532 19 32-43 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8
177 532 19 52-28 Bushing Steering
180 532 19 54-57 Chassis
181 532 40 47-96 Bushing Mtg. Fender Crgo
182 532 19 30-57 Dash Lower
183 874 78 05-20 Bolt 5/16-18 unc x 1-1/4
186 532 18 97-53 Insert Grille
189 817 00 05-12 Screw 5/16-18 x 3/4
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
196 532 40 97-28 Console Asm. Deck Lift
207 532 18 38-33 Bezel RH
208 532 18 38-32 Bezel LH
213 874 76 05-12 Bolt 5/16-18 x 3/4
217 532 15 65-24 Rod Pivot Hood
218 532 19 63-95 X-Piece Hood Stop
222 532 13 77-29 Screw 1/4-20 x 5/8
228 532 19 51-61 Stud Fastener
230 532 17 01-65 Bolt Shoulder 5/16-18
235 532 40 61-29 Spacer Fender
236 873 93 05-00 Nut Lock 5/16-18 unc
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
CHASSIS AND ENCLOSURES
