Jonsered LTH18 User Manual

R
DECALS
34
6
2
1
5,8
4,10
3,9
11
7
KEY PART
NO. NO. DESCRIPTION
3 532152247 Decal Hood RH
4 532152248 Decal Hood LH
WHEELS & TIRES
KEY PART
NO. NO. DESCRIPTION
1 532059192 Cap Valve Tire
2 532065139 Stem Valve
3 532106222 Tire F Ts 15 X 6 0 - 6 Service
4 532059904 Tube Front (Service Item Only)
5 532138336 Rim Asm 6" front Silver Service
6 532124957 Fitting Grease (Front Wheel Only)
7 532124959 Bearing Flange (Front Wheel Only)
8 532138337 Rim Asm 8"rear Silver Service
9 532122082 Tire R Ts 20 10 C Service
10 532124926 Tube Rear (Service Item Only)
11 532104757 Cap, Hub Axle Blk 1.50 x 1.00
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
