Jorvik JMT7 Electric Mountain Trike
9
How To Assemble This Tricycle
Handlebars
Remove the white safety cover/spacer.
Make sure the front fork is aligned to the
wheel.
Simply mount the handlebar onto the top
of the front fork stem
Tighten the bolt of stem centre by using
a 5mm Allen key. (Image 1 and 2)
Tighten the 2 bolts below using a 5mm
Allen key. (Image 3 and 4)
Adjust the height by loosening the
adjuster bolt, raise to desired height then
re-tighten. (Image 5)
Image 3Image 2Image 1
Image 5Image 4
