jost JSK52DV - Page 9

9
1500 gr.
1/2´´
1/2´´
SW19
1500 gr.
6-12 mm
80
Nm
14
25 26
4 Repair work
14 Bushing
25 Hexagon head screw
26 Retaining sheet
Insert screws and bend over the locking tab.
 Drive out the bushing（14 )
Apply a thin coating of grease to the new bearing bushing (14) and carefully drive it into the pedestal
Apply a thin coating of grease to the inside of the pedestals before installing the bearing bushes.
