8
12
!
80
1/2´´
1/2´´
SW19
1500 gr.
6-12 mm
25
26
1500 gr.
4 Repair work
4.1
To remove and install bushing
Note
Release the screws and undo them.
12 swivel pin with stop
Drive out the swivel pin with stop.
（
12
）。
Lifting
hole
The fifth wheel coupling may only be lifted using suitable lifting gear.
When lifting, please pay
attention to safety
T
ake the fifth wheel coupling off the tractor unit
and place it on work bench.
25
Hexagon head screw
26 Retaining sheet
