4 Installation
4.1 Introduction.
The procedures for installing the radio units / transceiver are described in table 4.1 below.
It is recommended that these procedures are completed in the order shown.
Install equipment into 19” sub racks (equipment cabinet)
Connect chassis stud to system earth or cabinet
Figure 3.2-1 (TX)
Figure 3.4-1 (RX)
Figure 3.6-1
(PSU)
Connect remote connectors as required
Connect antenna connectors
Connect DC supply (if required)
Connect AC supply (if required
Table 4.1-1, Installation procedures
4.2 Initial inspection
Items included for a TA-7650C transmitter
Power supply unit PSU-7002
Interconnecting cord between TA and PSU
Items included for a RA-7203C receiver
On receipt of the radio units, remove all transit packaging and check that there is no damage to the
equipment. If damage is evident, contact Jotron immediately and retain the original transit
packaging.
1
Variants may include: - Reduced maximum power level <50 W
- PM modulation
- Frequency range 156 – 162MHz
- Inband ptt signalling (option: 84358)
- Inband squelch signalling (option: 84358)
