Jotron AS| TR7750C: Operators Manual Installation
Page 4-10
P/N: 84748 (G)
Menu path:
TX config ►
Parameter
Range
Default
Details
Keying
(TX)
Source
Mic, line, txkey,
txgnd, inband
Mic, txkey
Determines what signal that will be used as
the source for keying the transmitter.
Any combinations can be set
Mic: Local PTT input from a
microphone, where the PTT is
connected to pin 4 and 8(gnd) on
the Mic/headset connector.
Line: Keying from a phantom
signal on the line input. Pin 3 and 6
on the Rem/TR connector.
Txkey: The transmitter is keyed by
an external voltage on the
TXKEY_P and TXKEY_N input
pins. Signals located on Pin 7 and
8 on the | connector.
Txgnd: The transmitter is keyed by
a signal on the TX_KEY_G input
pin Signals are located on Pin 4
and 8 (gnd) on the REM/TR
connector.
Inband: The transmitter is keyed
using an inband tone (see also
inband frequency and inband
sensitivity)
Table 4.6-6, Key Source settings
